Canon imagePROGRAF iPF8000S Service Manual

Chapter 3
3-10
3.1.2.4 Installing the Media Take-up Unit
0014-8925
1) In case the basket is installed, lift the front basket rod [1] gently to release the lock, lower the rod toward the front, and push it all the way back. Remove the front
basket rod from the basket arms L and R, than roll up the basket cloth and put it behind the bottom stand stay.
F-3-18
[1]
