Canon imagePROGRAF iPF8000S Service Manual

Chapter 7
7-2
7.1.2 Map of the Service Mode
0017-8416
The hierarchy of menus and parameters in the Service Mode is as shown below.
T-7-1
First Level Second Level Third Level Fourth Level Fifth Level
DISPLAY PRINTINF YES/NO : Select YES to
execute print
SYSTEM S/N
TYPE
LF TYPE
TMP
SIZE LF
SIZE LF
SIZE CR
SIZE CR
HEAD S/N R
S/N L
LOT R
LOT L
INK PC
---
M
WARNING 1
---
20
ERROR 1
---
20
INK CHECK 000 00000
I/O DISPLAY I/O DISPLAY 1
I/O DISPLAY 2
ADJUST PRINT PATTERN NOZZLE 1 : Press the [OK]
button to execute
OPTICAL AXIS : Press the [OK]
button to execute
LF TUNING
LF TUNING 2
SENSOR CHECK
HEAD ADJ. AUTO HEAD ADJ ROUGH : Press the [OK]
button to execute
MANUAL HEAD ADJ DETAIL : Press the [OK]
button to execute
BASIC : Press the [OK]
button to execute
ADJ. SETTING A A-1 : Adjustment
value entry
---
A-48 : Adjustment
value entry
---
F F-1 : Adjustment
value entry
F-2 : Adjustment
value entry
SAVE SETTINGS YES/NO
RESET SETTINGS YES/NO
NOZZLE CHK POS. YES/NO
GAP CALIB. YES/NO
CHANGE LF TYPE 0/1
REPLACE CUTTER YES/NO
