Chapter 1
1-2
F-1-2
T-1-1
[1] Upper Cover [12] Stand
[2] Ink Tank Cover [13] Maintenance Cartridge Cover
[3] Ejection Slot [14] Maintenance Cartridge
[4] Ejection Guide [15] Operation Panel
[5] Output Stacker [16] Expansion Board Slot
[6] Roll Holder Slot [17] Ethernet Port
[7] Holder Stopper [18] USB Port
[8] Roll Holder [19] Accessory Pocket
[9] Paper Feed Slot [20] Media Take-up Unit Power Inlet
[10] Ejection Support [21] Power Supply Connector
[11] Release Lever [22] Carrying Handles
[18]
[19]
[20]
[21]
[17]
[16]
[22]
To Next Page
