Canon imagePROGRAF iPF8000S Service Manual

Chapter 4
4-3
F-4-3
F-4-4
<Legend > c: Connector h: Hook s: Screw
Flexible cable (c5)
Ink tube unit
2. Ink Tube Unit Disassembly Flow
Printer
Automatic ink drain
Manual ink drain
Left/right circle covers (L) (h1)
Left/right circle covers (S) (h1)
Left/right side covers (s3, h2)
Left/right tank cover unit (s3)
Upper rear cover (s5)
Upper cover
Open left/right ink tank units
(s4)
Upper left/upper right covers
(h1)
Rear cover right (s4)
Rear cover left (s2)
Left/right printhead
Left/right joint bases
Ink tube joint
Ink tube cover (s2)
Flexible cable (c3)
Carriage PCB cover (s4)
Carriage unit
Move the carriage to
above the platen
Head management sensor
(s1)
Cable fixer base (s3)
Lift unit (s5)
Cutter unit
Pulley base (s3)
<Legend > c: Connector h: Hook s: Screw
Printer
Right circle cover (L) (h1)
Right circle cover (S) (h1)
Right side covers (s3, h2)
Operation panel (h1, c2)
Right front cover (s2)
Upper right cover (h1)
Purge unit (c1, s3)
Move the carriage to
above the platen
3. Purge Unit Disassembly Flow
