Canon imagePROGRAF iPF8000S Service Manual

Chapter 6
6-13
T-6-26
18 H1-DASLK_LICC2 IN Head(L) analogue switch clock signal
19 VH_DIS IN VH selection single
20 GND - GND
21 H1-E-DATA-9-EV_B IN Even head(L) data signal 9(E)
22 GND - GND
23 /H1-E-HE-9_B IN Head(L) heat enable signal 9(E)
24 GND - GND
25 H1-F-DATA-10-EV_B IN Even head(L) data signal 10(F)
26 GND - GND
27 H1-F-DATA-11-EV_B IN Even head(L) data signal 11(F)
28 GND - GND
29 /H1-F-HE-11_B IN Head(L) heat enable signal 11(F)
30 GND - GND
31 H1-F-DATA-11-OD_B IN Odd head(L) data signal 11(F)
32 GND - GND
33 /H1-F-HE-10_B IN Head(L) heat enable signal 10(F)
34 GND - GND
35 H1-E-DATA-9-OD_B IN Odd head(L) data signal 9(E)
36 GND - GND
37 H1-F-DATA-10-OD_B IN Odd head(L) data signal 10(F)
38 GND - GND
39 H1-E-DATA-8-OD_B IN Odd head(L) data signal 8(E)
40 GND - GND
41 /H1-E-HE-8_B IN Head(L) heat enable signal 8(E)
42 GND - GND
43 H1-D-DATA-7-OD_B IN Odd head(L) data signal 7(D)
44 GND - GND
45 H-DASH_LICC2 IN Head analogue switch A/D trigger signal
46 /OUT_ENB IN Head data enable signal
47 /CRCOVER OUT Carriage cover sensor output signal
48 GND - GND
49 ENCODER_B OUT Carriage encoder output signal B
50 ENCODER_A OUT Carriage encoder output signal A
J103
Pin Number Signal name IN/OUT Function
1 /H1-B-HE-2_B IN Head(L) heat enable signal 2(B)
2 GND - GND
3 H1-A-DATA-1-OD_B IN Odd head(L) data signal 1(A)
4 GND - GND
5 H1-A-DATA-0-OD_B IN Odd head(L) data signal 0(A)
6 GND - GND
7 /H1-A-HE-0_B IN Head(L) heat enable signal 0(A)
8 GND - GND
9 H1-A-DATA-0-EV_B IN Even head(L) data signal 0(A)
10 GND - GND
11 /H1-A-HE-1_B IN Head(L) heat enable signal 1(A)
12 GND - GND
13 H1-A-DATA-1-EV_B IN Even head(L) data signal 1(A)
14 GND - GND
15 H1-B-DATA-2-EV_B IN Even head(L) data signal 2(B)
16 GND - GND
17 H1-B-DATA-3-EV_B IN Even head(L) data signal 3(B)
18 GND - GND
19 H1-C-DATA-4-EV_B IN Even head(L) data signal 4(C)
20 GND - GND
21 /H1-B-HE-3_B IN Head(L) heat enable signal 3(B)
22 GND - GND
23 H1-C-DATA-5-EV_B IN Even head(L) data signal 5(C)
24 GND - GND
25 /H1_LT_B IN Head(L) latch signal
26 GND - GND
27 H1_CLKP IN Head(L) clock signal P
28 H1_CLKN IN Head(L) clock signal N
J102
Pin Number Signal name IN/OUT Function
