Chapter 7
7-15
13) MEDIASIZE2 ROLL: Counters related to roll media printing
T-7-27
14) MEDIASIZE1 CUT: Counters related to cut sheet printing
T-7-28
15) MEDIASIZE2 CUT: Counters related to cut sheet printing
T-7-29
16) HEAD DOT CNT.1: Counter related to dot count
T-7-30
Display Description Unit
D-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (data size) m2/Sq.f
D-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (data size) m2/Sq.f
D-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size) m2/Sq.f
D-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size) m2/Sq.f
D-SQ -17 Cumulative print area of paper less than 17 inches (data size) m2/Sq.f
D-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(data size)
sheets
D-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(data size)
sheets
D-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(data size)
sheets
D-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(data size)
sheets
D-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size) sheets
Display Description Unit
P-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (physical size) m2/Sq.f
P-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (physical size) m2/Sq.f
P-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (physical size) m2/Sq.f
P-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (physical size) m2/Sq.f
P-SQ -17 Cumulative print area of paper less than 17 inches (physical size) m2/Sq.f
P-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(physical size)
sheets
P-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(physical size)
sheets
P-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(physical size)
sheets
P-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(physical size)
sheets
P-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (physical size) sheets
Display Description Unit
D-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (data size) m2/Sq.f
D-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (data size) m2/Sq.f
D-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size) m2/Sq.f
D-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size) m2/Sq.f
D-SQ -17 Cumulative print area of paper less than 17 inches (data size) m2/Sq.f
D-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(data size)
sheets
D-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(data size)
sheets
D-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(data size)
sheets
D-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(data size)
sheets
D-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size) sheets
Display Description Unit
XX XX: Ink color
Dot counts of each colors of the currently installed printhead
(x 1,000,000) dots
TTL Total dot counts of each colors of the currently installed printhead (x 1,000,000) dots
