Canon imageRUNNER ADVANCE C5045 Series User Manual

8
8
8-110
8-110
COPIER > DISPLAY > HT-C
TGT-B-K2 ARCDAT scrn B Bk-clr target VL(1/2 SPD)
Lv.2 Details To display the Bk-patch target value of screen B in ARCDAT
control at 1/2 speed.
Use case When checking ARCDAT control operation
Adj/set/operate method -
Caution Take necessary action in accordance with the instructions from
the Quality Support Division.
Display/adj/set range 0 to 1023
Unit -
Appropriate target value 0 to 700
Default value -
Required time -
Related service mode -
Related user mode -
Supplement/memo -
TGT-C-Y2 ARCDAT scrn C Y-color target VL(1/2 SPD)
Lv.2 Details To display the Y-patch target value of screen C in ARCDAT
control at 1/2 speed.
Use case When checking ARCDAT control operation
Adj/set/operate method -
Caution Take necessary action in accordance with the instructions from
the Quality Support Division.
Display/adj/set range 0 to 1023
Unit -
Appropriate target value 0 to 700
Default value -
Required time -
Related service mode -
Related user mode -
Supplement/memo -
TGT-C-M2 ARCDAT scrn C M-color target VL(1/2 SPD)
Lv.2 Details To display the M-patch target value of screen C in ARCDAT
control at 1/2 speed.
Use case When checking ARCDAT control operation
Adj/set/operate method -
Caution Take necessary action in accordance with the instructions from
the Quality Support Division.
Display/adj/set range 0 to 1023
Unit -
Appropriate target value 0 to 700
Default value -
Required time -
Related service mode -
Related user mode -
Supplement/memo -
COPIER > DISPLAY > HT-C
TGT-C-C2 ARCDAT scrn C C-color target VL(1/2 SPD)
Lv.2 Details To display the C-patch target value of screen C in ARCDAT
control at 1/2 speed.
Use case When checking ARCDAT control operation
Adj/set/operate method -
Caution Take necessary action in accordance with the instructions from
the Quality Support Division.
Display/adj/set range 0 to 1023
Unit -
Appropriate target value 0 to 700
Default value -
Required time -
Related service mode -
Related user mode -
Supplement/memo -
TGT-C-K2 ARCDAT scrn C Bk-clr target VL(1/2 SPD)
Lv.2 Details To display the Bk-patch target value of screen C in ARCDAT
control at 1/2 speed.
Use case When checking ARCDAT control operation
Adj/set/operate method -
Caution Take necessary action in accordance with the instructions from
the Quality Support Division.
Display/adj/set range 0 to 1023
Unit -
Appropriate target value 0 to 700
Default value -
Required time -
Related service mode -
Related user mode -
Supplement/memo -
TGT-C-Y3 ARCDAT scrn C Y-color target VL(1/3 SPD)
Lv.2 Details To display the Y-patch target value of screen C in ARCDAT
control at 1/3 speed.
Use case When checking ARCDAT control operation
Adj/set/operate method -
Caution Take necessary action in accordance with the instructions from
the Quality Support Division.
Display/adj/set range 0 to 1023
Unit -
Appropriate target value 0 to 700
Default value -
Required time -
Related service mode -
Related user mode -
Supplement/memo -

Canon imageRUNNER ADVANCE C5045 Series Specifications

General

Resolution	1200 x 1200 dpi
Paper Capacity (Maximum)	5, 000 sheets
Duplexing	Automatic
Monthly Duty Cycle	Up to 150, 000 pages
Operation Panel	8.4-inch SVGA Full-Color TFT Screen
Scanning Resolution	600 x 600 dpi
Output Paper Capacity (Standard)	250 sheets
Power Consumption (Maximum)	1.5 kW
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	45 ppm (BW/Color)
Connectivity	Ethernet, USB 2.0
Type	Color Laser Multifunction Printer
Functions	Copy, Print, Scan, Send, Store
Hard Disk Drive	160GB
Maximum Copy Reservation	5 jobs
Warm-Up Time	38 seconds
Acceptable Paper Sizes	A3, A4, A5, B4, B5
Acceptable Paper Weights	52-300 gsm
Weight	Approx. 242.5 lbs
Maximum Mailboxes Supported	100 User Inboxes
