COPIER > ADJUST > FEED-ADJ
ADJ-C4RE Write start pstn in horz scan:Cst4 2nd
Lv.1 Details To adjust the image write start position in the horizontal scanning
direction for 2nd side when feeding paper from the Cassette 4.
As the value is incremented by 1, the margin on the left edge of
paper is increased by 0.1 mm.
+: Left margin becomes larger (An image moves to the right.)
-: Left margin becomes smaller (An image moves to the left.)
When replacing the Reader Controller PCB/clearing RAM data,
enter the value of service label.
Use case When replacing the Reader Controller PCB/clearing RAM data
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -100 to 100
Unit 0.1 mm
Appropriate target value -
Default value 0
Required time -
Related service mode -
Related user mode -
Supplement/memo -
ADJ-DKRE Write start pstn in horz scan: Deck 2nd
Lv.1 Details To adjust the image write start position in the horizontal scanning
direction for 2nd side when feeding paper from the Paper Deck.
As the value is incremented by 1, the margin on the left edge of
paper is increased by 0.1 mm.
+: Left margin becomes larger. (An image moves to the right.)
-: Left margin becomes smaller. (An image moves to the left.)
When replacing the DC Controller PCB/clearing RAM data, enter
the value of service label.
Use case When replacing the Reader Controller PCB/clearing RAM data
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -100 to 100
Unit 0.1 mm
Appropriate target value -
Default value 0
Required time -
Related service mode -
Related user mode -
Supplement/memo -
COPIER > ADJUST > FEED-ADJ
ADJ-MFRE Write start pstn in horz scan:MPTray 2nd
Lv.1 Details To adjust the image write start position in the horizontal scanning
direction for 2nd side when feeding paper from the Multi-purpose
Tray.
As the value is incremented by 1, the margin on the left edge of
paper is increased by 0.1 mm.
+: Left margin becomes larger. (An image moves to the right.)
-: Left margin becomes smaller. (An image moves to the left.)
When replacing the Reader Controller PCB/clearing RAM data,
enter the value of service label.
Use case When replacing the Reader Controller PCB/clearing RAM data
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -100 to 100
Unit 0.1 mm
Appropriate target value -
Default value 0
Required time -
Related service mode -
Related user mode -
Supplement/memo -
REG-THCK Rgst start timing adj: Heavy, 1/2 speed
Lv.1 Details To adjust the top margin by changing the timing to turn ON the
Registration Motor when feeding heavy paper.
As the value is incremented by 1, the margin on the left edge of
paper is increased by 0.1 mm.
+: Top margin becomes smaller. (An image moves upward.)
-: Top margin becomes larger. (An image moves downward.)
Use case -
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -50 to 50
Unit 0.1 mm
Appropriate target value -
Default value 0
Required time -
Related service mode -
Related user mode -
Supplement/memo -
To Next Page
