Canon imageRUNNER ADVANCE C5045 Series User Manual

8
8
8-218
8-218
COPIER > ADJUST > HV-TR
2TR-E22 Sec trns ATVC crrnt: norm hmdy envlp 2nd
Lv.1 Details To adjust the offset value of target current for the 2nd side
of envelope at secondary transfer ATVC control (in normal
humidity).
If the value is too large, density loss due to excessive transfer or
high-voltage mottled image etc. occurs and if it is too small, burst
image or mottled image etc. occurs.
Use case When adjusting the secondary transfer bias according to the
conditions
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -128 to 127
Unit 1 uA
Appropriate target value -20 to 20
Default value 0
Required time -
Related service mode COPIER> ADJUST> HV-TR> 2TR-P22
Related user mode -
Supplement/memo -
2TR-E13 Sec trns ATVC crrnt: high hmdy envlp 1st
Lv.1 Details To adjust the offset value of target current for the 1st side of
envelope at secondary transfer ATVC control (in high humidity).
If the value is too large, density loss due to excessive transfer or
high-voltage mottled image etc. occurs and if it is too small, burst
image or mottled image etc. occurs.
Use case When adjusting the secondary transfer bias according to the
conditions
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -128 to 127
Unit 1 uA
Appropriate target value -20 to 20
Default value 0
Required time -
Related service mode COPIER> ADJUST> HV-TR> 2TR-P13
Related user mode -
Supplement/memo -
COPIER > ADJUST > HV-TR
2TR-E23 Sec trns ATVC crrnt: high hmdy envlp 2nd
Lv.1 Details To adjust the offset value of target current for the 2nd side of
envelope at secondary transfer ATVC control (in high humidity).
If the value is too large, density loss due to excessive transfer or
high-voltage mottled image etc. occurs and if it is too small, burst
image or mottled image etc. occurs.
Use case When adjusting the secondary transfer bias according to the
conditions
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -128 to 127
Unit 1 uA
Appropriate target value -20 to 20
Default value 0
Required time -
Related service mode COPIER> ADJUST> HV-TR> 2TR-P23
Related user mode -
Supplement/memo -
2TR-SH23 Sec trns ATVC crrnt: high hmdy hvy2 2nd
Lv.1 Details To adjust the offset value of target current for the 2nd side
of heavy2 paper at secondary transfer ATVC control (in high
humidity).
If the value is too large, density loss due to excessive transfer or
high-voltage mottled image etc. occurs and if it is too small, burst
image or mottled image etc. occurs.
Use case When adjusting the secondary transfer bias according to the
conditions
Adj/set/operate method Enter the setting value (switch negative/positive by -/+ key) and
press OK key.
Caution -
Display/adj/set range -128 to 127
Unit 1 uA
Appropriate target value -20 to 20
Default value 0
Required time -
Related service mode COPIER> ADJUST> HV-TR> 2TR-H23
Related user mode -
Supplement/memo -

Canon imageRUNNER ADVANCE C5045 Series Specifications

General

Resolution	1200 x 1200 dpi
Paper Capacity (Maximum)	5, 000 sheets
Duplexing	Automatic
Monthly Duty Cycle	Up to 150, 000 pages
Operation Panel	8.4-inch SVGA Full-Color TFT Screen
Scanning Resolution	600 x 600 dpi
Output Paper Capacity (Standard)	250 sheets
Power Consumption (Maximum)	1.5 kW
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	45 ppm (BW/Color)
Connectivity	Ethernet, USB 2.0
Type	Color Laser Multifunction Printer
Functions	Copy, Print, Scan, Send, Store
Hard Disk Drive	160GB
Maximum Copy Reservation	5 jobs
Warm-Up Time	38 seconds
Acceptable Paper Sizes	A3, A4, A5, B4, B5
Acceptable Paper Weights	52-300 gsm
Weight	Approx. 242.5 lbs
Maximum Mailboxes Supported	100 User Inboxes
