Combination Table of Accessory Installation
Combination of the Options installing to the Right Side
of the Host Machine
MEMO:
The following table shows the combination of accessories that are set at the right side of
the host machine.
When setting the accessories indicated in the table, refer to the table below and check the
combination before the setup.
When installing the USB Device Port-B1, install it before installing the following options.
•
•
•
Utility Tray-A1 Voice Guidance
Kit-F1
Voice Operation
Kit-C1
Card
Reader-C1
Utility Tray-A1 - no no yes
Voice Guidance
Kit-F1
no - no yes
Voice Operation
Kit-C1
no no - yes
Card Reader-C1 yes yes yes -
yes: Available no: Unavailable
T-9-1T-9-1
Combination of the Options Related to the HDD
When installing the HDD options (5 products indicated below), refer to the pages indicated in
the following table.
2.5inch/80GB HDD-C1
2.5inch/250GB HDD-D1
Removable HDD Kit-AC1
HDD Mirroring Kit-D1
HDD HDD Data Encryption & Mirroring Kit-C1
Reference Pages in the Manual According to Product Combination
No. Combination of Product Reference Pages in the Manual
1
HDD (80GB/250GB) p. 9-43 to p. 9-56
2
Removable HDD Kit
p. 9-57 to p. 9-75
3
HDD (80GB/250GB) +
Removable HDD Kit
4
HDD (80GB/250GB) +
HDD Mirroring Kit
p. 9-43 to p. 9-56, p. 9-76 to p. 9-21
5
HDD (80GB/250GB) +
Removable HDD Kit +
HDD Mirroring Kit
p. 9-57 to p. 9-21
6
HDD (80GB/250GB) +
HDD Data Encryption & Mirroring Kit
p. 9-43 to p. 9-56
Refer to the Installation Manual and Instruction
Sheet of CASE-1 and CASE-2 packed with the HDD
Data Encryption & Mirroring Kit.
7
Removable HDD Kit +
HDD Data Encryption & Mirroring Kit
p. 9-57 to p. 9-75
Refer to the Installation Manual and Instruction
Sheet of CASE-1 and CASE-2 packed with the HDD
Data Encryption & Mirroring Kit.
8
HDD (80GB/250GB) +
Removable HDD Kit +
HDD Data Encryption & Mirroring Kit
•
•
•
•
•
T-9-2T-9-2
