- PE sensor cable
- Paper feed motor harness ass'y
Re-connect the cable.
(3) Strange sound at power-on:
Replace the purge drive system
unit.
5 times ASF (cam)
sensor error
[5700] (1) Cable connection:
- PE sensor cable, etc.
Re-connect the cable.
- ASF unit
- PE sensor board
ass'y
- Logic board ass'y
6 times Internal
temperature
error
[5400] (1) Cable connection:
- Between the spur unit and the logic
board, J703 connector, etc.
Re-connect the cable.
- Spur unit
- Logic board ass'y
- Print head
7 times Ink absorber
full
[5B00]
[5B01]
(1) Ink absorber condition:
Replace the ink absorber, and reset
the ink absorber counter value in
the EEPROM.
- Absorber kit
8 times Print head
temperature rise
error
[5200] (1) Print head condition (face surface and
mold):
If a burn mark or heat deformation
is seen on the face surface or the
mold, replace the print head.
(2) Head contact pin condition of the
carriage unit:
If the pin is bent or deformed,
replace the carriage unit.
(3) Cable connection:
- CR FFC (J500, J501, J502)
Re-connect the cable.
If any damage or breakage of the
cable is found, replace the carriage
unit.
- Print head
- Carriage unit
9 times EEPROM error [6800]
[6801]
(1) Part replacement:
Replace the logic board ass'y.
- Logic board ass'y
10 times VH monitor
error
[B200] (1) Print head condition (face surface and
mold):
If a burn mark or heat deformation
is seen on the face surface or the
mold, replace the print head and
the logic board in set. (Be sure to
replace them at the same time.)
(2) Burn mark or heat deformation of the
logic board:
If a burn mark or heat deformation
is seen on the logic board, replace
- Print head and logic
board ass'y (replace
them at the same
time)
- AC adapter
- Carriage unit
To Next Page
