*1: Install the Service Tool to a licensed computer.
LF / Eject correction To correct line feeding when
necessary.
- At paper feed roller replacement
- At platen unit replacement
- At logic board replacement
- At LF slit film replacement
- At timing slit film replacement
Service Tool
*1
,
(1) In the LF/EJECT
Correction section,
click Print to print the
LF/EJ correction pattern.
(2) According to the printed
pattern, set the
correction value in the
LF/EJECT Correction
section.
5 min.
Carriage rail position
adjustment
To set the carriage rail to the original
position prior to removal or
replacement of the carriage unit and
maintain the head-to-paper distance,
put a mark on the main chassis before
removal of the carriage unit.
Put a mark using a sharp-
pointed metallic stick, such
as a wimble.
1 min.
- The screws securing the paper feed motor may be loosened only at replacement of the paper
feed motor unit.
