96 Using the Canon Advanced Printing Technology Chapter 3
Using the LBP-810 Status Window
The Status Window is a program used to display the status of jobs and
perform printer operations.
Window area Description
Menu bar Contains menu options to control the
Status Window and the printer.
Printer icon Displays the current printing status and
error conditions.
Printer status message
area
Displays the current status of the printer.
Error message area Gives a description of situations requiring
action.
Tool bar
Menu bar
Progress bar
Job information
area
Error message
area
Printer status
message area
Status bar
Animation area
Tab window
Printer icon
