No. Parts Name Main Unit Re-
mark
s
Reference Adjastment during parts
replacement
[11] Reader Unit Upper Cover Reader Unit - “Removing the Reader Unit Upper
Cover” on page 144
“After Replacing the Reader
Upper Cover Unit” on page
145
[12] Scoopup sheet holder Reader Unit - “Removing the Scoopup sheet
holder” on page 142
“After Replacing the Scoopup
Sheet Holder” on page 143
