FUNCTION
■ CCD
COPIER > FUNCTION > CCD
Item Description
DF-WLVL1
Title White level adj in book mode: color
Details To adjust the white level for copyboard scanning automatically by setting the paper which is usually
used by the user on the Copyboard Glass.
Use case • When replacing the Copyboard Glass
• When replacing the CIS Unit
• When replacing the ADF / Reader Unit
Adj/set/operate method 1. Set paper on the Copyboard Glass.
2. Select the item, and then press Yes key.
Caution Be sure to execute DF-WLVL2 in a row.
Related service mode COPIER > ADJUST > CCD > DFTAR-R
COPIER > ADJUST > CCD > DFTAR-G
COPIER > ADJUST > CCD > DFTAR-B
COPIER > FUNCTION > CCD > DF-WLVL2
DF-WLVL2
Title White level adj in ADF mode: color
Details To adjust the white level for ADF scanning automatically by setting the paper which is usually used
by the user on the ADF.
Use case • When replacing the Copyboard Glass
• When replacing the CIS Unit
• When replacing the ADF / Reader Unit
Adj/set/operate method 1. Set paper on the ADF.
2. Select the item, and then press Yes key.
Caution Be sure to execute this item after DF-WLVL1.
Related service mode COPIER > ADJUST > CCD > DFTAR-R
COPIER > ADJUST > CCD > DFTAR-G
COPIER > ADJUST > CCD > DFTAR-B
COPIER > FUNCTION > CCD > DF-WLVL1
DF-WLVL3
Title White level adj in book mode (B&W)
Details To adjust the white level for copyboard scanning automatically by setting the paper which is usually
used by the user on the Copyboard Glass.
Use case • When replacing the Copyboard Glass
• When replacing the CIS Unit
• When replacing the ADF / Reader Unit
Adj/set/operate method 1. Set paper on the Copyboard Glass.
2. Select the item, and then press Yes key.
Caution Be sure to execute DF-WLVL4 in a row.
Related service mode COPIER > ADJUST > CCD > DFTAR-BW
COPIER > FUNCTION > CCD > DF-WLVL4
DF-WLVL4
Title White level adj in ADF mode (B&W)
Details To adjust the white level for ADF scanning automatically by setting the paper which is usually used
by the user on the DADF.
Use case • When replacing the Copyboard Glass
• When replacing the CIS Unit
• When replacing the ADF / Reader Unit
Adj/set/operate method 1. Set paper on the ADF.
2. Select the item, and then press Yes key.
Caution Be sure to execute this item after DF-WLVL3.
Related service mode COPIER > ADJUST > CCD > DFTAR-BW
COPIER > FUNCTION > CCD > DF-WLVL3
CL-AGC
8. Service Mode
277
