PC-D320/PC-D340/FAX-L400 Chapter 4: Maintenance and Service
4-47
Figure 4-13 Service Data 3
No. 001, 007, 008, 012, 014, 029 to 055 and 071 to 080 are not used. Do not
change their settings
#3 NUMERIC Param.
001:
002:
003:
004:
005:
006:
007:
008:
009:
010:
011:
012:
013:
014:
015:
016:
017:
018:
019:
020:
021:
022:
023:
024:
025:
026:
027:
028:
055:
Not used
RTN signal transmission condition (1)
RTN signal transmission condition (2)
RTN signal transmission condition (3)
Pause time for NCC (before the ID code)
Pause time for NCC (after the ID code)
Not used
Not used
The number of digits in telephone
compared against TSI signal to be matched
for restricted receiving function
Line connection detection time (T0 timer)
T1 timer (Rx)
Not used
Maximum time allowed to receive one line
of image data
Not used
Hooking detection time
Pseudo RBT transmission from CML on time
until start
Pseudo RBT signal pattern: On time
Pseudo RBT signal pattern: Off time (short)
Pseudo RBT signal pattern: Off time (long)
Pseudo ring pattern: On time setting
Pseudo ring pattern: Off time setting (short)
Pseudo ring pattern: Off time setting (long)
FAX/TEL switching function : Signal detection level
Pseudo-RBT signal transmission level
answering machine connection function
signal detection level
Not used
Not used
Menu pop-up time
Not used
(Numeric parameter settings)
Default
0
10 (10%)
15 (15 times)
12 (12 lines)
4 (sec)
4 (sec)
0
0
6 (6 digits)
5500 (55 sec)
3500 (35 sec)
0 (0 line)
1300 (13 sec)
0
120 (100 ms)
2 (2 seconds)
100 (1000 ms)
0 (0 ms)
400 (4000 ms)
100 (1000 ms)
0 (0 ms)
400 (4000 ms)
0
10
60
0
0
3 (3 sec)
Item 029 to 055:
Range
(1~99)
(2~99)
(1~99)
(1~60)
(1~60)
(1~20)
(0~9999)
(0~9999)
(0~65535)
(500~9999)
(0~999)
(0~9)
(0~999)
(0~999)
(0~999)
(0~999)
(0~999)
(0~999)
(0~9)
(0~20)
(0~999)
(1~60)
