PC-D320/PC-D340/FAX-L400 Chapter 4: Maintenance and Service
4-70
6.2 Test Mode Flowchart
To operate the test mode, after pressing the Additional Function key, press the # key and select
“SERVICE MODE”. After this, select “TEST MODE” with the - or + keys, and press the OK
key.
To end test mode, keep pressing the Stop/Reset key while pressing the Additional Function
key.
Figure 4-19 Test Mode Menu
[1] D-RAM
[2] CCD TEST
[3] PRINT
[4] MODEM NCU
[5] AGING TEST
[6] FACULTY TEST
[1] D-RAM
[2] D-RAM
[3] I-RAM
[4] OPT MEM
[08] GAIN AUTO ADJUST
[0] AMI PT
[1] WHT
[2] BLK
[3] STRPS
[4] CHKRS
[5] CHKRS2
[6] ENDUR
[7] BK/WHT
[8] BIAS
[9] CHKRS3
[*] PRT AR
[#] CRG
[1] RELAY
[2] FREQ
[4] G3 Tx
[5] DTMF Tx TEST
[6] TONE Rx
[8] V.34 G3 Tx TEST
[1] G3 4800BPS Tx
[3] SENSOR
[4] ADF
[5] STAMP
[6] SPEAKER
[7] OPERATION PANEL
[9] LINE DETECT
TEST MODE
“ ” indicates that these items
are not used in the field.
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
