PC-D320/PC-D340/FAX-L400 Chapter 2: Technical Reference
2-10
3. PAPER SUPPLY SECTION
The paper supply section is designed to separate the recording sheets stacked on the Cassette or
MP tray one by one for forwarding to the printer unit.
Figure 2-5 Paper supply section
Pick-up roller
Main motor
Pick-up solenoid
