PC-D320/PC-D340/FAX-L400 Chapter 1: General Description
1-9
Printing range
Item A4 Letter Legal
Effective 206 ±2.0 mm 212 ±2.0 mm 212 ±2.0 mm
Printing width (8.11"±0.08") (8.35"±0.08") (8.35"±0.08")
Effective 287.5 ±3.0 mm 269.9 ±3.0 mm 346.1 ±3.5 mm
Printing length (11.32"±0.12") (10.63"±0.12") (13.63"±0.14")
Left margin 2.0 ±2.0 mm 2.0 ±2.0 mm 2.0 ±2.0 mm
(0.08" ±0.08") (0.08" ±0.08") (0.08" ±0.08")
Right margin 2.0 ±3.0 mm 2.0 ±3.0 mm 2.0 ±3.0 mm
(0.08" ±0.12") (0.08" ±0.12") (0.08" ±0.12")
Top margin 3.5 ±2.0 mm 3.5 ±2.0 mm 3.5 ±2.0 mm
(0.14" ±0.08") (0.14" ±0.08") (0.14" ±0.08")
Bottom margin 3.5 ±2.0 mm 3.5 ±2.0 mm 3.5 ±2.0 mm
(0.14" ±0.08") (0.14" ±0.08") (0.14" ±0.08")
Figure 1-2 Printing Range
Paper trailing edge
PRINTING RANGE
PRINTING DROP OUT RANGE
Right marginLeft margin
Top margin
Bottom margin
Effective scanning width
Paper leading edge
Effective scanning length
