PC-D320/PC-D340/FAX-L400 Chapter 1: General Description
1-17
Figure 1-7 External View (2)
PC-D340
ADF (AUTOMATIC DOCUMENT FEEDER)
Holds documents for copying and feeds
them automatically into the scanning unit.
DOCUMENT OUTPUT TRAY
Documents come out here.
OPERATION PANEL
Controls the machine.
LEFT COVER
Open it when you
output paper face
up or remove
jammed paper.
POWER CORD CONNECTOR
DOCUMENT FEEDER TRAY
Place documents for copying.
USB INTERFACE CONNECTOR
