PC-D320/PC-D340/FAX-L400 Chapter 1: General Description
1-20
Figure 1-10 Operation Panel (2)
System Monitor Key
Checks the status of fax, copy, print and report jobs.
In Use/Memory indicator
Flashes green when a fax is being received or sent. Lights green when the reservation of fax transmission is set,
or a fax is received into the memory.
Alarm indicator
Flashes orange when the machine has a problem such as a paper jam.
(The error message is displayed in the LCD.)
COPY Key
Switches standby display to Copy mode.
FAX Key
Switches standby display to Fax mode.
Energy Saver Key
Sets or cancels the energy saver mode manually. The key lights green when the energy saver mode is set, and
goes off when the mode is cancelled.
Numeric Keys
Enter numbers when dialling or registering fax/telephone numbers. Also, enter characters when registering
names.
Stop/Reset Key
Cancels sending or receiving faxes and other operations, and brings back the standby display in the LCD.
Start Key
Starts sending faxes.
