Front View
A: Paper Support
Open to load paper in the rear tray.
B: Paper Support Extension
Extend to load paper in the rear tray.
C: Feed Slot Cover
Prevents anything from falling into the feed slot.
Open it to slide the paper guides, and close it before printing.
D: Rear Tray
Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same
time, and fed automatically one sheet at a time.
Loading Paper in the Rear Tray
Loading Envelopes in Rear Tray
E: Paper Guides
Align with both sides of the paper stack.
F: Cassette Cover
Detach to load paper in the cassette.
G: Paper Guides
Align with right/left/front sides of the paper stack.
H: Multi-purpose Tray
Use when printing on printable discs and other media.
172
