Rear View
A: USB Port
Plug in the USB cable to connect the printer with a computer.
B: Wired LAN Connector
Plug in the LAN cable to connect the printer to a LAN.
C: Power Cord Connector
Plug in the supplied power cord.
D: Transport Unit Cover
Open when removing jammed paper.
E: Rear Cover
Detach when removing jammed paper.
Important
• Do not touch the metal casing.
• Do not plug in or unplug the USB cable or LAN cable while the printer is printing with the computer. This
can cause trouble.
