Canon TS705 - LCD and Operation Panel

LCD and Operation Panel
Pressing the Setup button (A) on the operation panel displays the Setup menu screen, which enables you
to perform printer settings and maintenance.
Selecting a Menu or Setting Item
In a menu screen or settings screen, use the button (B) to select an item or option, and then press
the OK button (C) to proceed with the procedure.
To return to the previous screen, press the Back button (D).
Example: Changing the setting for Prevent Abrasion.
1. Press Setup button (A).
2. Use button (B) to select Device settings and press OK button (C).
3. Press OK button (C).
4. Press OK button (C).
5. Use button (B) to change setting and press OK button (C).
Network Status Indication
Wi-Fi setting and the network status indicate by the icon in the standby screen.
183
