Step 3 Adjust the Image
46
Adjusting the Image Position
To adjust the screen position up, down, left, or right, press the LENS-SHIFT button
on the remote control or the LENS button on the projector. It can change the
projected screen to the most suitable position by moving the position of the lens up/
down/left/right. (P129)
1 Press either the LENS-SHIFT button on the remote control or the LENS
button on the projector three times to display the lens shift adjustment
window.
2 Press the pointer buttons to adjust.
To raise or lower the image, use the [ ] / [ ] buttons on the remote control or
projector.
To move the image left or right, use the [ ] / [ ] buttons on the remote control
or projector.
To continue moving the image in a specific direction, hold down the
corresponding button.
3 When the desired position is reached, press the OK button.
• The available range for lens shift (percentage of movement relative to the screen size)
varies depending on the lens unit which is used. (P129)
• Lens shift is not available in each corner for the Short Fixed Lens (RS-IL03WF) or in the
top left and top right for the other lenses. (P130)
Remote control Projector
Press three times.*
Remote control Projector
Screen
