3
SPECIFICATIONS
Power Requirements: 90 to 264 VAC (50/60 Hz) at 0.4A
Enclosure Type: NEMA 4X/IP66:
Enclosure Size: 10 7/8"W x 8 3/16"H x 3 1/8"D (276mm W x 208mm H x 79mm D)
Weight: 9.2lbs (
Size and Weight DOES NOT include Gimbal
)
Operating Environment: Temperature: 14 to 104 ºF (-10 to +40 ºC)
Humidity: 90% non-condensing (maximum)
Display: 12-digit, 0.8" high, 14-segment LCD
Transducer Excitation: 12 VDC
Signal Input Range: 1.0 mV min. to 40 mV max. (with dead load boost)
Number of Load Cells: 14 each, 350 OHM minimum resistance
Load Cell Cable Length: 1500 feet maximum with sense lines.
30 feet maximum without sense lines
Maximum Displayed
Weight Value
9,999,999
Division Value: 1, 2, or 5 x 10, 1, 0.1, 0.01, 0.001 and 0.0001 commercial
0 to 99, non-commercial
Sensitivity:
NON-COMMERCIAL
NTEP
CANADA
OIML
0.15 uV/e
0.3uV/e (Class III/IIIL)
0.3uV/e (Class III/IIIHD)
0.7 uV/e (Class III)
Scale Divisions:
NON-COMMERCIAL
NTEP
CANADA
OIML
100 to 240,000
100 to 10,000 (Class III/IIIL)
100 to 10,000 (Class III/IIIHD)
100 to 10,000 (Class III)
Internal Resolution: 1 part in 16,777,216
Tare Capacity: Six Digits (999,999)
Sample Rate: 1 to 100 samples per second, selectable
Auto Zero Range: 0.5 or 1 through 9 divisions
Weighing Units: Tons, Pounds, Metric Tons, Kilograms, Grams, Ounces, Custom
Keypad: Membrane type with 27 color-coded keys
Standard I/O: (1) Bi-directional RS232 and 20mA
(1) RS232/20mA output only
(1) Infrared (IR) Data Port
Optional I/O: 14 bit Analog Output (0 to 10v, 4 to 20mA)
Certifications:
This equipment is certified to comply with the requirements for a Class III/IIIL device by the
•
National Conference on Weights and Measurements (Certificate No. 01-011)
•
Measurement Canada (Approval No. AM-5397)
• and for a Class III device by OIML R-76 (Certificate No. DK 0199.47).
Consult factory for
other requirements
