Examples
application no. code description
showcase Master
1 MX30M25HO0
MPXPRO: complete Master controller with EEV management (including RS485 and RTC) 5 relays + Stepper EEV, 2 PWM,
0 to 10 Vdc, NTC/PT1000, horizontal screw connector kit
1 IR00UGC300 Terminal (green LEDs, keypad, buzzer, commissioning port, IR)
3 NTC0*0HP00 NTC probe, IP67, cable l= *, -50T50 °C
1 NTC0*0HF01 NTC probe, IP67, cable l= * m, -50T90 °C STRAP-ON, multiple package (10 pcs.)
1 SPKT0013R0
Ratiometric pressure probes for MPXPRO: ratiometric pressure transducer with 1/4” SAE steel female connector, 7/16”
-20 UNF -2B, PACKARD connector (single package), 0 to 5 Vdc, -1 to 9.3 bar (0 to 150 psiA)
1 SPKC00*310
Ratiometric pressure probes for MPXPRO: ratiometric pressure transducer with 1/4” SAE steel female connector, 7/16”
-20 UNF -2B, PACKARD connector (single package), IP67, cable l= * m with co-moulded PACKARD connector for SPKT*
1 E2V**BSF00 EEV with 12 mm copper ttings, sizes from 9 to 24
1 E2VCABS600 Shielded cable with connector for EEV, l= 6 m
showcase Slave
1 MX30S25HO0
MPXPRO: complete Slave controller 5 relays + Stepper EEV, 2 PWM, 0 to 10 Vdc, NTC/PT1000, horizontal screw
connector kit
1 IR00XGC300 Display (green LEDs, keypad, buzzer, commissioning port, IR)
3 NTC0*0HP00 NTC probe, IP67, cable l= *, -50T50 °C
1 NTC0*0HF01 NTC probe, IP67, cable l= * m, -50T90 °C STRAP-ON, multiple package (10 pcs.)
1 E2V**BSF00 EEV with 12 mm copper ttings, sizes from 9 to 24
1 E2VCABS600 Shielded cable with connector for EEV, l= 6 m
cold room Master only
1 MX30M25HO0
MPXPRO: complete Master controller with EEV management (including RS485 and RTC) 5 relays + Stepper EEV, 2 PWM,
0 to 10 Vdc, NTC/PT1000, horizontal screw connector kit
1 IR00UGC300 Terminal (green LEDs, keypad)
2/3 NTC0*0HP00 NTC probe, IP67, cable l= *, -50T50 °C
1 NTC0*0HF01 NTC probe, IP67, cable l= * m, -50T90 °C STRAP-ON, multiple package (10 pcs.)
1 SPKT0013R0
Ratiometric pressure probes for MPXPRO: ratiometric pressure transducer with 1/4” SAE steel female connector, 7/16”
-20 UNF -2B, PACKARD connector (single package), 0 to 5 Vdc, -1 to 9.3 bar (0 to 150 psiA)
1 SPKC00*310
Ratiometric pressure probes for MPXPRO: ratiometric pressure transducer with 1/4” SAE steel female connector, 7/16”
-20 UNF -2B, PACKARD connector (single package), IP67, cable l= * m with co-moulded PACKARD connector for SPKT*
1 E2V**BSF00 EEV with 12 mm copper ttings, sizes from 9 to 24
1 E2VCABS600 Shielded cable with connector for EEV, l= 6 m
Tab. 10.c
