4 Chapter 2 Cephalometric Modality Overview
Mobile Components
Figure 1 illustrates the:
• Up and down movement of the unit mobile components
• Rotation and translation movement of the rotative arm and the cephalostat
Figure 1 CS 8100SC Unit Mobile Components
Figure 2 CS 8100SC 3D Unit Mobile Components
Important: The patient can enter either the left side or the right
side of the unit.
