32 Chapter 5 Acquiring Images using the Cephalometric Modality
Launching the X-ray
To launch the X-ray, follow these steps:
1. Leave the X-ray room and close the door. You must keep visual contact with the patient during
acquisition.
Figure 6
Frontal AP
Figure 7 Frontal PA
Important: If you have a problem that requires you to stop the
acquisition, release the exposure button of the remote control or
press the red emergency stop button.
