Cephalometric Modality User guide for CS 8100 Family and CS 8100 3D Family_SM987_Ed02 5
General Functional Components
The following figures illustrate the general functional components of the units.
Figure 3 CS 8100SC Functional Components
1 Unit rotative arm 11 Unit column
2 Unit head 12 Frankfort positioning indicator
3 Emergency stop knob 13 Secondary collimator
4 ON/OFF button 14 Nasion support
5 Cephalostat arm 15 Head clamps and ear cones
6 Cephalostat head 16 Cephalometric digital sensor
7 X-ray source assembly 17 X-ray remote control
8 Head and chin rest 18 Carpus panel (optional)
9 Chin rest and bite block 19 Computer hosting the imaging and the
acquisition software
10 Panoramic digital sensor
17
19
4
12
5
13
3
14
15
16
7
8
9
10
1
11
6
2
18
