Type 1
During installation, all conduit hole plugs shall be removed, and all conduit holes shall be used.
Closed-Loop Crimp Terminal Size
Drive Model RVLF
Fuse Type
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
200 V Class Single-Phase Drives
RVLFA110040A Bussmann 20CT 690V 20A
RVLFA110075A Bussmann 25ET 690V 25A
Drive Model RVLF
Fuse Type
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
200 V Class Single-Phase Drives
RVLFA120040FA Bussmann 10CT/16CT 690V 10A/ 690V 16A
RVLFA120075FA Bussmann 10CT/20CT 690V 10A/ 690V 20A
RVLFB120150FA Bussmann 16CT 690V 16A
RVLFB120220FA Bussmann 20CT 690V 20A
Drive
Model
Wire Gauge
Terminal
Crimp
Terminal
Tool Insulation Cap
mm
2
, (AWG)
RVLF
R/L1 x S/L2 x
T/L3
U/T1 x V/T2 x
W/T3
Screws
Model
No.
Machine No. Model No.
RVLFA110040A 2.1 (14) TIC2
RVLFA110075A 3.3 (12) M4 R3.5-4 TIC3.5
RVLFA*20040** 1.3 (16) TIC2
RVLFA*20075** 2.1 (14) TIC2
RVLFB*20150** 3.3 (12)
M4
R5.5-4 TIC 3.5
RVLFB*20220** 5.3 (10) R5.5-4 TIC 3.5
RVLFB340075FA 2.1 (14)
R3.5-4
TIC2
RVLFB340150FA 2.1 (14) TIC2
RVLFB340220FA 2.1 (14) TIC2
RVLFC340370FA 2.1 (14) R2-3.5 TIC2
RVLFC340550FA 8.4 (8)
M5 R8-5
TIC8
RVLFD340750FA 8.4 (8) TIC8
RVLFD3401100FA 8.4 (8) TIC8
