Table 4.2 Analog input property list (READ)
No.
Object
Name
Description Unit Classication Range
AI0 TM2 AVI AVI input Percent R 0 - 100
AI1 TM2 ACI ACI input Percent R 0 - 100
AI2 Error code
Recent fault
message
No Units R 0 –43
AI3 Freq cmd
Frequency
command
HZ R 0 - 599
AI4 Frequency Output frequency HZ R 0 -599
AI5 Current Output current Amps R
AI6 Control Mode Control mode No Units R 0 - 1
AI7 Motor R-Volt
Motor rated
voltage
Volt R
AI8 Motor R-HP Motor rated power horsepower R
AI9 Motor R-RPM
Motor rated
rotation speed
rpm R
AI10 Motor R-Hz
Motor rated
frequency
HZ R
AI11 CarrierFreq Carrier frequency KiloHertz R 1 - 16
AI12 Comm Station
INV communication station No Units R 1 – 32
AI13 BaudRate Baudrate setting No Units R 0 – 3
AI14 BacnetSel
Communication mode
selection
No Units R 0 – 2
AI15 DevInstance Inverter number No Units R 1 - 254
