Supervision Data (Only for reading)
Bit Meaning 1 0
Sequent input
value
0 MFIT S1 ON OFF
1 MFIT S2 ON OFF
2 MFIT S3 ON OFF
3 MFIT S4 ON OFF
4 MFIT S5 ON OFF
5 (unused)
6 Relay R1 ON OFF
Terminal output
7 (unused)
9~F (unused)
Register Content
2522H
MFIT state
2523H Frequency command
2524H Frequency output
2525H Voltage command (10/1V)
2526H DC voltage command (1/1V)
2527H Current output (10/1A)
2528H Reserved
2529H Reserved
252AH PID Feedback value (100% / Max output frequency, 10/1% )
252BH PID input value (100% / Max output frequency, 10/1% , sign attached)
252CH TM2 AIN input value (1001 / 10V)
252DH TM2 AV2 input value (1001 / 10V)
252EH Ready-to-use
252FH Ready-to-use
