144
COIL #1, COIL #2
The unloader solenoid output is a triac output. The triac is
rated for 115/208-230 VAC with a maximum continuous
rating of 30 VA. The smart controller energizes the unloader
solenoid coil in an on/off sequence per the 0 to 10 VDC ana-
log input signal received by the smart controller.
LIQUID INJECTION
The liquid injection solenoid output is a triac output. The
triac is rated for 115/208-230 VAC with a maximum contin-
uous rating of 30 VA. The smart controller will energize the
liquid injection solenoid as required to provide compressor
motor cooling and maintain compressor discharge below
230 F.
