38
screws be re-torqued 24 hours after new fiber gaskets are
installed.
NOTE: Compressors with metal core gaskets do not
require re-torque.
REMOVE, INSPECT AND REPLACE BEARING
HEAD ASSEMBLY
An oil pressure tap is located in the bearing head assem-
bly used on all 06D refrigeration duty, newer 06D A/C
duty, and all 06E refrigeration and A/C duty compres-
sors (Fig. 6 and Fig. 7).
For 06D, E, CC oil pressure, see page 72, Section 3.9.
The oil pump assembly is contained in the pump end
bearing head aluminum casting. The pump end main
bearing is a machined part of this casting. No insert bear-
ing is required.
