APPENDIX A — DISPLAY TABLES (cont)
Inputs Mode and Sub-Mode Directory
Outputs Mode and Sub-Mode Directory
SUB-MODE ITEM DISPLAY ITEM DESCRIPTION COMMENT
GEN.I
GENERAL INPUTS
STST STRT/STOP Start/Stop Switch
ID.F.A ON/OFF Indoor Fan Status-CIRA
Y.1 ON/OFF Y1 Thermostat Input
Y.2 ON/OFF Y2 Thermostat Input
ID.F.B ON/OFF Indoor Fan Status-CIRB
Y.3 ON/OFF Y3 Thermostat Input
Y.4 ON/OFF Y4 Thermostat Input
DLS1 ON/OFF Demand Limit Switch 1
DLS2 ON/OFF Demand Limit Switch 2
CRCT
CIRCUIT INPUTS
FKA1 ON/OFF Compressor A1 Feedback
FKA2 ON/OFF Compressor A2 Feedback
FKA3 ON/OFF Compressor A3 Feedback
HPSA OPEN/CLSE High Pressure Switch A
FKB1 ON/OFF Compressor B1 Feedback
FKB2 ON/OFF Compressor B2 Feedback
FKB3 ON/OFF Compressor B3 Feedback
HPSB OPEN/CLSE High Pressure Switch B
4-20
4-20 MA INPUTS
DMND XX.X mA 4-20 ma Demand Signal
RSET XX.X mA 4-20 ma Reset Signal
CL.MA XX.X mA Cap Req/Setpoint Signal
SUB-MODE ITEM DISPLAY ITEM DESCRIPTION COMMENT
GEN.O
GENERAL OUTPUTS
FAN1 ON/OFF Fan 1 Relay
FAN2 ON/OFF Fan 2 Relay
FAN3 ON/OFF Fan 3 Relay
FAN4 ON/OFF Fan 4 Relay
FAN5 ON/OFF Fan 5 Relay
MLV.R ON/OFF Minimum Load Valve Relay
V.HPA XXX.X % Var Head Press Out Cir A
V.HPB XXX.X % Var Head Press Out Cir B
CIR.A
OUTPUTS CIRCUIT A
CC.A1 ON/OFF Compressor A1 Relay
DPE.R XXX Comp A1 Load Percent
CC.A2 ON/OFF Compressor A2 Relay
CC.A3 ON/OFF Compressor A3 Relay
LSV.A ON/OFF Liquid Line Solenoid A
L.V.A2 ON/OFF Liquid Line Solenoid A2
CIR.B
OUTPUTS CIRCUIT B
CC.B1 ON/OFF Compressor B1 Relay
CC.B2 ON/OFF Compressor B2 Relay
CC.B3 ON/OFF Compressor B3 Relay
LSV.B ON/OFF Liquid Line Solenoid B
L.V.B2 ON/OFF Liquid Line Solenoid B2
