Carrier SmartVu - Page 27

27
5 - USER INTERFACE: MENU STRUCTURE
CPU Load
No. Status Default Unit Displayed text* Description
1 0 to 100 - % CPU load CPU utilization
2 0 to 100 - % RAM Memory utilization RAM usage
3 0 to 100 - % FLASH Memory utilization Flash memory usage
*Depends on the selected language (English by default).
EOLRES – EOL Resistor
No. Status Default Unit Displayed text* Description
1 disable/enable disable - End of Line Res. J6 (LEN) End of line resistor J6 (LEN bus)
2 disable/enable disable - End of Line Res. J7 (CCN) End of line resistor J7 (CCN bus)
3 disable/enable disable - End of Line Resistor J8 End of line resistor J8
4 disable/enable disable - End of Line Resistor J10 End of line resistor J10 (Modbus)
*Depends on the selected language (English by default).
Network
No. Status Default Unit Displayed text* Description
1 IP Network Interface J5 (eth0): IP Network Interface J5 (Ethernet 0):
2 - xx:xx:xx:xx:xx:xx - MAC Address MAC Address
3 - 169.254.1.1 - TCP/IP Address
TCP/IP Address: Changing the IP address and mask is possible but
a reboot is mandatory if Modbus TCP or BACnet IP is enabled (the
reboot is required to make changes e󰀨ective).
4 - 255.255.255.0 - Subnet Mask Subnet Mask
5 - 169.254.1.3 - Default Gateway Default Gateway
6 - 255.255.0.0 - Gateway Mask Gateway Mask
7 - 169.254.1.3 - Domain Name Server (DNS) Domain Name Server (DNS)
8 - 169.254.1.4
*Depends on the selected language (English by default).
Date/Time
No. Status Displayed text* Description
1 on/o󰀨 Daylight Saving Time Summer/winter time activation
2 Greenwich Mean Time (UTC) Location Time zone
3 YYYY/MM/DD, HH:MM:SS Date/Time Current date and time (must be set manually)
4 no/yes Today is a Holiday
Information about holidays (read-only). Please note that holidays are set in the
Holiday menu (see also section 5.4)
5 no/yes Tomorrow is a Holiday
Information about the upcoming holiday period (read-only). Please note that
holidays are set in the Holiday menu (see also section 5.4)
*Depends on the selected language (English by default).
