6 - STANDARD CONTROL OPERATIONS AND OPTIONS
6.15 - Trending
This function enables to visualise the operations of the unit and
monitor a set of selected parameters.
To display trends
1. Go to the Main menu.
2. Select Trendings (TRENDING).
3. Select parameters to be displayed and press the Save button
in the lower-left part of the screen.
4. Press the Trending button to display the graph showing
trends for the set of selected parameters.
■ Press to navigate across the timeline or press
to go to the beginning or the end of the selected period.
■ Press the Zoom in button to magnify the view or
the Zoom out button to expand the viewed area.
■ Press the Refresh button to reload data.
For web interface only:
■ Set the time range (start/end dates and time) at the bottom of
the Trendings Plot screen and press the Arrow button on
the right side to display the graph showing the performance of
the unit within a selected period of time.
