5.5 - Network menu
The Network menu allows the user to change network setting for
BACnet/Modbus and define e-mail accounts used for alarm
notications (see section 8.3).
5 - USER INTERFACE: MENU STRUCTURE
NOTE: If you need to add an option (BACnet/Modbus), please
contact your local service representative.
NETWORK – Network Menu
Icon Name Displayed text* Description
MODBUSRS
ModbusRTU Cong. Modbus RTU conguration
MODBUSIP
ModbusTCP/IP Cong. Modbus TCP/IP conguration
BACnet
BACnet Standard Conf. BACnet standard conguration
EMAILCFG
EMail Conguration Email settings
*Depends on the selected language (English by default).
MODBUSRS – ModbusRTU Cong.
No. Name Status Default Unit Displayed text* Description
1 modrt_en no/yes no - RTU Server Enable RTU Server Enable
2 ser_UID 1 to 247 1 - Server UID Server UID
3 metric no/yes yes - Metric Unit Metric Unit
4 swap_b 0 to 1 0 - Swap Bytes Swap Bytes
5 0 = Big Endian 0 = Big Endian
6 1 = Little Endian 1 = Little Endian
7 baudrate 0 to 2 0 - Baudrate Baudrate
8 0 = 9600 0 = 9600
9 1 = 19200 1 = 19200
10 2 = 38400 2 = 38400
11 parity 0 to 2 0 - Parity Parity
12 0 = No Parity 0 = No Parity
13 1 = Odd Parity 1 = Odd Parity
14 2 = Even Parity 2 = Even Parity
15 stop_bit 0 to 1 0 - Stop bit Stop bit
16 0 = One Stop Bit 0 = One Stop Bit
17 1 = Two Stop Bits 1 = Two Stop Bits
18 real_typ 0 to 1 1 - Real type management Real type management
19 0 = Float X10 0 = Float X10
20 1 = IEEE 754 1 = IEEE 754
21 reg32bit 0 to 1 1 - Enable 32 bits registers Enable 32 bits registers
22 0 = IR/HR in 16 bit mode 0 = IR/HR in 16 bit mode
23 1 = IR/HR in 32 bit mode 1 = IR/HR in 32 bit mode
*Depends on the selected language (English by default).
MODBUSIP – ModbusTCP/IP Cong.
No. Name Status Default Unit Displayed text* Description
1 modip_en no/yes no - TCP/IP Server Enable TCP/IP Server Enable
2 ser_UID 1 to 247 1 - Server UID Server UID
3 port_nbr 0 to 65535 502 - Port Number Port Number
4 metric no/yes yes - Metric Unit Metric Unit
5 swap_b 0 to 1 0 - Swap Bytes Swap Bytes
6 0 = Big Endian 0 = Big Endian
7 1 = Little Endian 1 = Little Endian
