50
Menu-EXIO.02: Set Ext Input 1
Function
Set Ext Input 1
Set Range
(0 ~ 5)
Display Part
Meaning
EIN1. 00
External In1 is zero key
EIN1. 01
External In1 is tare/tareless key
EIN1. 02
External In1 is print key
EIN1. 03
External In1 is hold keyy
EIN1. 04
External In1 is hold clear key
EIN1. 05
External In1 is start key
Menu-EXIO.03: Set Ext Input 2
Function
Set Ext Input 2
Set Range
(0 ~ 5)
Display Part
Meaning
EIN2. 00
External In2 is zero key
EIN2. 01
External In2 is tare/tareless key
EIN2. 02
External In2 is print key
EIN2. 03
External In2 is hold key
EIN2. 04
External In2 is hold clear key
EIN2. 05
External In2 is start key
Menu-EXIO.04: Relay Reverse On/Off
Function
Relay Reverse On/Off
Set Range
(0, 1)
Display Part
Meaning
EREV. 00
Relay Reverse OFF
EREV. 01
Relay Reverse ON
Menu-EXIO.05: Set Start Delay Time for completed Relay
Function
Set Start Delay Time for completed Relay(T1)
Set Range
(0 ~ 99)
Display Part
Meaning
ERST. 10
Delayed by 00 x 0.1 Sec
Menu-EXIO.06: Set Operating Duration Time for completed Relay
Function
Set Operating Duration Time for completed Relay(T2)
Set Range
(0 ~ 99)
Display Part
Meaning
EROT. 10
Delayed by 00 x 0.1 Sec
