CAS CI-170A - Page 48

49
Weighing Output Information per Mode
Relay Mode
OUT 1
OUT 2
OUT 3
OUT 4
ㅁ 1_Limit Mode
Zero
Step 1
SP1 ≤ W
Step 2
SP2 ≤ W
Finish(Stable)
ㅁ 2_Limit type Checker Mode
Zero
LOW
W ≤ SP1
HIGH
SP2 ≤ W
Finish(OK)
SP1< W<SP2
ㅁ 3_Checker Mode
Zero
LOW
W ≤SP1
HIGH
SP2 ≤W
Finish(OK)
SP1< W <SP2
ㅁ 4_Programmable Mode
Step 1
SP1≤W (ON)
W≤SP8 (OFF)
Step 2
SP2≤W (ON)
W≤SP7 (OFF)
Step 3
SP3≤W (ON)
W≤SP6 (OFF)
Step 4
SP4≤W (ON)
W≤SP5 (OFF)
ㅁ 5_Packer Mode
Zero
Step 1
W ≤ SP1-SP3
Step 2
W ≤ SP2-SP4
Finish
ㅁ 6_Checker Mode 2
Zero
LOW
W ≤SP1
HIGH
SP2 ≤W
Finish(OK)
SP1< W <SP2
ㅁ 7_Limit type Checker Mode 2
Zero
LOW
W ≤ SP1
HIGH
SP2 ≤ W
Finish(OK)
SP1< W<SP2
