▶ COMMAND MODE ( READ COMMAND )
TO →
INDICATOR
Command Description
Indicator Response
STX ID. NO. RTIM
BCC(9D) ETX
Command to transmit the
Indicator’s TIME DATA
Transmit TIME DATA (6)
- STX ID.NO. RTIM 000000 BCC ETX
STX ID. NO. RDAT
BCC(8C) ETX
Command to transmit the
Indicator’s DATE DATA
Transmit DATE DATA (6)
- STX ID. NO. RDAT 000000 BCC ETX
STX ID. NO. RCNO
BCC(93) ETX
Command to transmit the Code
Number
Transmit Code Number (6)
- STX ID. NO. RCNO 000000 BCC ETX
STX ID. NO. RPNO
BCC(A0) ETX
Command to transmit the Part
Number
Transmit P/N (2)
- STX ID. NO. RPNO 00 BCC ETX
STX ID. NO. RTAR
BCC(9A) ETX
Command to transmit the weight
value of “KEY Tare”
Transmit KEY Tare (6)
- STX ID. NO. RTAR 000000 BCC ETX
STX ID. NO. RCWT
BCC(A1) ETX
Command to transmit the “Current
Weight Value”
Transmit the “Current Weight Value”
- STX ID. NO. RCWT DATA1 BCC ETX
STX ID. NO. RSUB
BCC(9D) ETX
Command to transmit the “Sub-
total”
- STX ID. NO. RSUB P/N(2) CODE(6)
COUNT(6) S.T.W(8) BCC ETX
No Decimal Place
STX ID. NO. RGRD
BCC(90) ETX
Command to transmit the “Grand-
Total”
- STX ID.NO. RGRD P/N(2) CODE(6)
T_COUNT(6) G.T.W(10) BCC ETX
No Decimal Place
STX ID. NO.
RSP1 BCC ETX
Command to transmit the DATA of the
Step 1
Transmit the Step 1 DATA (6)
- STX ID.NO. RSP1 000000 BCC ETX
STX ID. NO.
RSP2 BCC ETX
Command to transmit the DATA of the
Step 2
Transmit the Step 2 DATA (6)
- STX ID.NO. RSP2 000000 BCC ETX
STX ID. NO.
RSP3 BCC ETX
Command to transmit the DATA of the
Step 3
Transmit the Step 3 DATA (6)
- STX ID.NO. RSP3 000000 BCC ETX
STX ID. NO.
RSP4 BCC ETX
Command to transmit the DATA of the
Step 4
Transmit the Step 4 DATA (6)
- STX ID.NO. RSP4 000000 BCC ETX
STX ID. NO.
RSP5 BCC ETX
Command to transmit the DATA of the
Step 5
Transmit the Step 5 DATA (6)
- STX ID.NO. RSP5 000000 BCC ETX
STX ID. NO.
RSP6 BCC ETX
Command to transmit the DATA of the
Step 6
Transmit the Step 6 DATA (6)
- STX ID.NO. RSP6 000000 BCC ETX
