CAS CI-170A - Write Commands

69
▶ COMMAND MODE ( WRITE COMMAND)
PC → INDICATOR
Command Description
Indicator Response
STX ID. NO. WTAR BCC(9F)
ETX
Command to set “TARE”
STX ID. NO. WTAR ACK BCC ETX
or
STX ID. NO. WTAR NAK BCC ETX
STX ID. NO. WTRS BCC(B1)
ETX
Command for “TARE RESET”
STX ID. NO. WTRS ACK BCC ETX
or
STX ID. NO. WTRS NAK BCC ETX
STX ID. NO. WZER BCC(A9)
ETX
Command to set “ZERO”
STX ID. NO. WZER ACK BCC ETX
or
STX ID. NO. WZER NAK BCC ETX
STX ID. NO. WPRT BCC(AE)
ETX
Command to run “PRINT”
STX ID. NO. WPRT ACK BCC ETX
or
STX ID. NO. WPRT NAK BCC ETX
STX ID. NO. WGPR BCC(A1)
ETX
Command to run “GRAND-
PRINT”
STX ID. NO. WGPR ACK BCC ETX
or
STX ID. NO. WGPR NAK BCC ETX
STX ID. NO. WDAT DATE
BCC(C6) ETX
ex) STX ID.NO WDAT 090903
C6 ETX
Command to convert the date of
the TIMER stored in the Indicator
to 2009. Sept. 3
rd
.
STX ID. NO. WDAT ACK BCC ETX
or
STX ID. NO. WDAT NAK BCC ETX
STX ID. NO. WTIM TIME
BCC(D7) ETX
ex) STX 01 WTIM 123456 D7
ETX
Command to convert the time of
the TIMER stored in the Indicator
to 12: 34: 56.
STX ID. NO. WTIM WCK BCC ETX
or
STX ID. NO. WTIM NAK BCC ETX
STX ID.NO. WPNO P/N(2)
BCC(06) ETX
ex) STX 01 WPNO 01 06
ETX
Command to change the “PART
NUMBER” to 01 value that is
being sent.
STX ID. NO. WPNO ACK BCC ETX
or
STX ID. NO. WPNO NAK BCC ETX
STX ID. NO. WCNO C/N(6)
BCC(CD) ETX
ex) STX 01 WCNO 123456 CD
ETX
Command to change the
“CODE” to the 123456 value that
is being sent.
STX ID. NO. WCNO ACK BCC ETX
or
STX ID. NO. WCNO NAK BCC ETX
STX ID. NO. WHOL BCC(9B)
ETX
Command to set “HOLD”
STX ID. NO. WHOL ACK BCC ETX
or
STX ID. NO. WHOL NAK BCC ETX
STX ID. NO. WHRS BCC(A5)
ETX
Command for “HOLD RESET”
STX ID. NO. WHRS ACK BCC ETX
or
STX ID. NO. WHRS NAK BCC ETX
STX ID. NO. WSTR
BCC ETX
Command for “START”
STX ID. NO. WSTR ACK BCC ETX
or
STX ID. NO. WSTR NAK BCC ETX
STX ID. NO. WSTO
BCC ETX
Command for “STOP”
STX ID. NO. WSTO ACK BCC ETX
or
STX ID. NO. WSTO NAK BCC ETX
STX ID. NO. WGRO
BCC ETX
Command for “Gross / Net”
STX ID. NO. WGRO ACK BCC ETX
or
STX ID. NO. WGRO NAK BCC ETX
STX ID. NO. WTNO
K / T(6) BCC ETX
ex) STX ID.NO WTNO 000000
BCC ETX
Command to change “Key Tare” to
the DATA value that is being sent
STX ID. NO. WTNO ACK BCC ETX
or
STX ID. NO. WTNO NAK BCC ETX
