STX ID. NO. WSP1
SP1(6) BCC ETX
ex) STX ID.NO WSP1 000000
BCC ETX
Command to change “Step 1” to the
DATA value that is being sent
STX ID. NO. WSP1 ACK BCC ETX
or
STX ID. NO. WSP1 NAK BCC ETX
STX ID. NO. WSP2
SP2(6) BCC ETX
ex) STX ID.NO WSP2 000000
BCC ETX
Command to change “Step 2” to the
DATA value that is being sent
STX ID. NO. WSP2 ACK BCC ETX
or
STX ID. NO. WSP2 NAK BCC ETX
STX ID. NO. WSP3
SP3(6) BCC ETX
ex) STX ID.NO WSP3 000000
BCC ETX
Command to change “Step 3” to the
DATA value that is being sent
STX ID. NO. WSP3 ACK BCC ETX
or
STX ID. NO. WSP3 NAK BCC ETX
STX ID. NO. WSP4
SP4(6) BCC ETX
ex) STX ID.NO WSP4 000000
BCC ETX
Command to change “Step 4” to the
DATA value that is being sent
STX ID. NO. WSP4 ACK BCC ETX
or
STX ID. NO. WSP4 NAK BCC ETX
STX ID. NO. WSP5
SP5(6) BCC ETX
ex) STX ID.NO WSP5 000000
BCC ETX
Command to change “Step 5” to the
DATA value that is being sent
STX ID. NO. WSP5 ACK BCC ETX
or
STX ID. NO. WSP5 NAK BCC ETX
STX ID. NO. WSP6
SP6(6) BCC ETX
ex) STX ID.NO WSP6 000000
BCC ETX
Command to change “Step 6” to the
DATA value that is being sent
STX ID. NO. WSP6 ACK BCC ETX
or
STX ID. NO. WSP6 NAK BCC ETX
※ACK = Transmission Complete (Normal Operation) , NAK = Transmission
Unsuccessful (Re-transmit)
※ BCC(XX) = XX is the BCC value when ID. NO. is set as 01.
