CAS CI-2001AS - FRONT PANEL (CI-2001 BS); Display Lamp Indicators (CI-2001 BS); Keyboard Functions (CI-2001 BS)

21
20
SET MODE
1. How to Enter
Turn on the power while pressing the “ENTER” key and SET menu starts.
2. Available Keys
Increase the first place set value to 1.
Move to the left by 1 place of the set value.
Initial(‘0’) of the set value. (CI-2001AS/BS kg type)
Initial(‘0’) of the set value. (CI-2001AS/BS kg/lb)
Move into next menu.
3. Set Value Conversion Menu(F01 - F14)
F01 : Select the primary base unit(kg/lb type)
F02 : Designation of serial port usage
F03 : Automatic zero tracking compensation
F04 : Digital filter
F07 : Weight back-up(power-on actual weight)
F09 : “ENTER” key usage(CI-2001AS kg type)
F09 : “ENTER” key usage(CI-2001AS kg/lb type)
F09 : “ENTER” key usage(CI-2001BS kg type)
F09 : “ENTER” key usage(CI-2001BS kg/lb type)
F10 : Device ID
F11 : Designation of serial interface baud rate
F12 : Designation of serial interface output mode
F13 : Set HOLD type
F14 : Select of clock option
PRINT
ENTER
( )
kg/lb
Select the primary base unit(CI-2001AS/BS kg/lb version)
0 Primary unit is kg
1 Primary unit is lb
F01
Serial port usage
0 Connection with computer and sub-display(CD-3000A)
1 Connection with serial printer
F02
Select the weight back-up mode
0 Weight back-up is off(Power on zero)
1 Weight back-up is on(Display setting weight)
F07
“ENTER” key usage(CI-2001AS kg version)
0 Not used
1 Total print key
2 HOLD key
F09
“ENTER” key usage(CI-2001AS kg/lb version)
0 Not used
1
- Print key(Press “PRINT” key)
- Total Print key(by pressing “PRINT” key more than 3 second.)
2 HOLD key
F09
Automatic zero tracking
0 None automatic zero
1 1 : 0.5 digit
~
9 9 : 4.5 digit
Autozero tracking will automatically
bring the display back to “0” when
there are small deviations.
F03
Digital filter
1 1 : Less vibration
~
9 9 : Much vibration
Adjust the set value according to the
condition.
F04
