7
TECHNICAL SPECIFICATION
■
Analog Part
LoadCell Excitation
Voltage
DC 5V, Up to 4 x 350Ω load cells
Zero adjust range
0.05 mV ～ 5 mV
2 μV/D (NTEP, OIML, KS)
Input Sensitivity
0.5 μV/D (Non NTEP, OIML, KS)
System Linearity
0.01％ F.S.
A/D internal resolution 1 / 200,000
A/D external resolution
1 / 5,000 (NTEP, OIML, KS)
1 / 30,000 (Non NTEP, OIML)
A/D conversion speed 10times/sec
