CAS CI-600D Series - Auxiliary Display Connection; Label Printer Connection

9-2. How to Connect an Auxiliary Display
TXD 2 O ----------------
O 2 Receive Data
GND 7 O ----------------
O 7 Signal Ground
9 pin port (male) 9 pin port (male)
RS-232C port of CI-600 Serial port of an auxiliary display
9-3. How to Connect a Label Printer (DLP)
TXD 2 O ---------------
O 2 Receive Data
RXD 3 O ---------------
O 3 Transmit Data
GND 7 O ---------------
O 5 Signal Ground
9 pin port (male) 9 pin port (male)
RS-232C port of CI-600 Serial port of DLP printer
Note. Refer to page 38 (Set Mode) for RS-232C communication and setting method.
73
