TEST 4
RS - 422/485 TEST with Computer (RS - 422/485 : Option)
KEY FUNCTION DISPLAY DESCRIPTION
ZERO Transmit ‘0’
TARE Transmit ‘1’
NET/GRS Transmit ‘2’
tESt 4
TEST 4 Condition
PRINT Transmit ‘4’
-----
Waiting for Transmission & reception
ENTER Transmit ‘8’
0 ----- 1
Receive : 1 Transmit : 0
UNIT Go to TEST5
2 ----- 1
Receive : 1 Transmit : 2
Note 1. Before testing, connect RS-422/485 of PC to COM2 port of Indicator and
run the communication program of PC.
Note 2. Before testing, connect COM2 port of Indicator.
Note 3. If you send ASCII code 0 ~ 9, Indicator receives this data.
If you press "1(ZERO key) " of indicator, you can check it in connected
device.
TEST 5
PRINTER TEST
KEY FUNCTION DISPLAY DESCRIPTION
UNIT
Go to
Normal Mode
ENTER
Testing the
Printer
tESt 5
TEST 5 Condition
Note 1. You should set the use of printer and printer in Device mode.
Note 2. If printer connection and setting is done successfully,
the display shows "good" and if not, the displays shows error message.
Note 3. Test Output Form of Printer is as follows.
And see " TEST OK " in the Hyper Terminal also.
TEST OK
