CAS NT-201A - Calibration Mode; How to Access Calibration Mode; Calibration Mode Overview

- 22 -
10. Calibration Mode
(zero span)
Zero and Span points to interpolate weight from Load Cell
Multi-point
Multi-point
mV/V
Real curve
weight
(full span)
Multi-point
Ideal
Multi-point
Multi-point
How to Go to Calibration Mode
Unfasten a Cal Switch Bolt on the rear side of indicator and then turn on
power while pressing CAL switch. The display show “rEAdY” “CALMOd”
Explain the Mode
KIND
Weight
Calibration
Gravity Sealing
Mode
Zero
Calibration
ZERO KEY G/N Key Long G/N KEY PRINT KEY
Engineer
Mode
Exit
Mode
Moving
KEY
rEAdY
C A L M o d
