CAS NT-201A - Checker Mode; Limit Mode; Select Limit Mode

- 32 -
SELECT LIMIT MODE
KEY FUNCTION DISPLAY VAL. DESCRIPTION
Select 0 or 1
0
Not use
1
Checker mode
ENTER
Save &
Go to F07
F06
2
Limit mode
UNIT Save & Exit Save & go to Normal Mode
[ CHECKER MODE]
Weight
Comm
Signal
(Low Limit) (High Limit)
0 kg 50 kg 100 kg
OUT
PUT
ZERO
1
0
LOW
1
0
HIGH
1
0
OK
1
0
Note 1. All outputs are generated regardless of stable state.
[ LIMIT MODE]
Weight
Comm
Signal
(Low Limit) (High Limit)
0 kg 50 kg 100 kg
OUT
PUT
ZERO
1
0
LOW
1
0
HIGH
1
0
OK
1
0
Note 1. OK signal is output when the state is stable only.
SELECT the METHOD of ACCUMULATION
